料号 |
国际
标准 |
电气
特性 |
主体
材料 |
额定
电压 |
额定电流 |
熔断特性(I/T) |
分断能力(BC) |
安规认证 |
|
311 |
UL248 |
快断/F
Quick-acting |
玻璃管
Glass |
125V
250V |
0.25A～10A |
1I:＞4h
2In:＜5s |
50A/250Vac
50-60Hz Cos∮=1.0 |
cULus:0.25A～10A |
|
312 |
UL248 |
慢断/T
Time-lag |
玻璃管
Glass |
125V
250V |
0.25A～10A |
1In:＞4h
2In:5s~60s |
50A/250Vac
50-60Hz Cos∮=1.0 |
cULus:0.25A～10A |
|
316 |
UL248 |
慢断/T
Time-lag |
陶瓷管
环氧涂层
Ceramic |
350V |
0.25A～10A |
1In:＞4h
2In:5s~60s |
50A/350Vac
50-60Hz Cos∮=1.0 |
cURus:0.25A～10A |
|
331 |
IEC60127
GB9364 |
快断/F
Quick-acting |
玻璃管
Glass |
250V |
0.25A～10A |
1.5In:＞1h
2.1In:＜30min
2.75In:10ms~3s
4In:3ms~0.3s
10In:＜20ms |
0.25A~3.5A:
50A/250Vac
4A~10A10In/250Vac
50-60Hz Cos∮=1.0 |
cURus:0.5A～10A
TUV:0.5A～6.3A
CQC:0.5A～6.3A |
|
332 |
IEC60127
GB9364 |
慢断/T
Time-lag |
玻璃管
Glass |
250V |
0.25A～10A |
1.5In:＞1h
2.1In:＜2min
2.75In:0.4s~10s
4In:0.15s~3s
10In:20ms~0.15s |
0.25A~3.5A:
50A/250Vac
4A~10A:10In/250Vac
50-60Hz Cos∮=1.0 |
cURus:0.25A～10A
TUV:0.5A～6.3A
CQC:0.5A～6.3A |
|
333 |
IEC60127
GB9364 |
快断/F
Quick-acting |
陶瓷管
Ceramic |
250V |
0.25A～10A |
1.5In:＞1h
2.1In:＜30min
2.75In:10ms~3s
4In:3ms~0.3s
10In:＜20ms |
0.25A~3.5A:
50A/250Vac
4A~10A:10In/250Vac
50-60Hz Cos∮=1.0 |
TUV:2A/6.3A |
|
334 |
IEC60127
GB9364 |
慢断/T
Time-lag |
陶瓷管
Ceramic |
250V |
0.25A～10A |
1.5In:＞1h
2.1In:＜2min
2.75In:0.4s~10s
4In:0.15s~3s
10In:20ms~0.15s |
0.25A~3.5A:
50A/250Vac
4A~10A:10In/250Vac
50-60Hz Cos∮=1.0 |
cURus:0.25A～10A
VDE:0.5A～5A
TUV:0.2A～0.315A/6.3A
CQC:0.5A～5A
PSE:1A~5A |
